Heavy-duty lock drive with 22 electric actuators
For a large lock system, S+R supplied 22 heavy electric actuators that move loads in the range of around 1,000 kN together.
Read projectReference projects
Concrete solutions show how S+R approaches projects.
These examples show industry, technical challenge, solution route and result.
Project examples
From load case to matching assembly.
The value lies in the technical translation: existing interface, environment, force, stroke, sensors, service and repeatability.
Hydraulic steel structures
Bridge drive: four electric actuators of around 350 kN each for two movable bridges
Two movable bridges are opened and closed by four electric actuators of around 350 kN each - weatherproof, controlled and serviceable over the long term.
Read project
Test benches & trial systems
Hexapod positioning: six electric actuators for a large telescope
For the fine alignment of a large astronomical research instrument, six electric actuators move a hexapod platform in six degrees of freedom - with forces up to around 77 kN per axis.
Read project Hydraulic steel structures
Heavy-duty actuator for a lock system after 20 years in service
A heavy electric actuator from a lock project returned to the S+R workshop after roughly 20 years in operation for service and service-life assessment.
Read project
Foundry & steelworks technology
Heavy-duty custom actuator for rough equipment
A robust electric actuator replaced a maintenance-heavy adjustment in a rough steelworks environment.
Read project
Machinery & plant engineering
Short installed length for a compact machine module
An existing machine geometry left very little axial space but required a robust lifting motion.
Read project Foundry & steelworks technology
Synchronised actuator pairs for parallel adjustment
Two electric actuators move a wide assembly with matching positioning logic.
Read project
Retrofit & maintenance
Retrofit solution for an older installed system
An existing drive was no longer economical to repair and needed a mechanically compatible replacement.
Read project
OEM & series assemblies
Standard-adjacent OEM assembly for repeat demand
A technical inquiry became a repeatable actuator assembly for serial demand, spare parts and planned follow-up call-offs.
Read project
Test benches & trial systems
Positioning axis for test bench and trial setup
A test bench needed electric lifting motion with traceable position and defined load range.
Read project
Process engineering
Protected adjustment in demanding surroundings
An adjustment near a demanding process needed to operate safely and remain serviceable.
Read project OEM & series assemblies
Pre-assembled units for series and spare-part supply
Pre-assembled electric actuators are prepared as tested call-off assemblies so framework agreements can be served quickly and on schedule.
Read project
